Description

Carlo Smart Power Supply and UPS Type SPUBC 120W

The new Carlo Gavazzi SPUBC puts you in the driving seat of your power management requirements, allocating power, in the most efficient way, between the load and the battery.The maximum available current for battery charging is set by means of a front trimmer. It can go from 20% to 100%, which means that it possible to charge with up to 5A. The priority though is always the load. If the load requires 80% of current, the current available for the battery is only the remaining 20% regardless of the setting. The SPUBC comes with 12VDC and 24VDC options, which allows a rated current of 10A and 5A respectively. SPUBC implements a comprehensive process called “Battery Care” that applies algorithms to obtain rapid and automatic charging, battery charge optimization over time, flat battery recovery and real time diagnostic during installation and operation. The Real Time autodiagnostic system, monitors battery faults such as battery sulphatation, elements in short circuit, accidental reverse polarity connection and battery disconnection or bad connection. All these can be easily detected and removed during installation and operation by the “diagnostic LED” Blinking Code. Continuous battery efficiency monitoring, reduces battery damage risk and allows safe operation in permanent connection.

This device is suitable for a selection of most common battery types. By means of built in jumpers it is possible to set preset curves. They are programmed for two charging levels, boost and float/trikle, but can be changed to single charging level by the user. In addition to the SPUBC, Carlo Gavazzi, also provides a selection of Racks for DIN rail mounting of the battery, with battery included upon request from 1.2Ah up to 12Ah capable of providing, depending upon load, from a few minutes to several hours of charge reserve.
